EACQ 3278 / EACR 3287 — Design of Structures B | Week 10: Foundations, Column Bases & Complete System Design
Bachelor of QS & Construction Management | Prepared from Duggal, McCormac & Salmon-Johnson | Page 1 of 23
EACQ 3278 / EACR 3287 — DESIGN OF STRUCTURES B
WEEK 10 LECTURE NOTES
Foundations, Column Bases & Complete Structural System Design
3-Hour Class | Year 3 Semester 2 | Bachelor of QS & Construction Management
References
Duggal Ch. 5 (pp. 189–223) | McCormac §7.7 & Appendix D (pp. 218–231, 688–
696) | Salmon & Johnson §13.9, §15.3–15.4 (pp. 746–752, 803–819)
LEARNING OUTCOMES — By the end of this session students will be able to:
1. Identify the structural purpose of column bases and select the appropriate type for a given
loading condition.
2. Design slab base plates for concentrically loaded columns using both the working stress
method (IS code, Duggal) and the LRFD/ASD method (AISC, McCormac).
3. Design gusset base plates for heavily loaded columns, including connection details.
4. Analyse base plate behaviour under eccentric loading and determine stress distributions and
anchor bolt forces.
5. Size anchor bolts and hold-down angles for uplift conditions.
6. Explain the role of column bases within a complete structural frame and demonstrate
system-level design integration.
EACQ 3278 / EACR 3287 — Design of Structures B | Week 10: Foundations, Column Bases & Complete System Design
Bachelor of QS & Construction Management | Prepared from Duggal, McCormac & Salmon-Johnson | Page 2 of 23
PART 1 | COLUMN BASES — TYPES, BEHAVIOUR & SLAB BASE DESIGN
1.1 What Is a Column Base and Why Is It Needed?
A steel column transmits its compressive load — often hundreds of kilonewtons — down to a concrete footing or
pedestal. Without a proper base, the column bearing area would be far too small, producing bearing stresses that
crush the concrete. The column base plate serves three purposes:
• Load distribution: spreads the concentrated column load over a sufficient bearing area so that contact
stresses in the concrete remain within permissible limits.
• Alignment: maintains the column plumb and at its correct plan position during and after erection.
• Connection to foundation: transfers any bending moments or horizontal shear forces into the concrete
pedestal, particularly important under wind and seismic loading.
Reference: Duggal §5.1, p. 189
1.2 Types of Column Bases
Duggal (§5.2) classifies column bases into two broad categories:
Type
Description
When Used
Slab Base
A single flat plate — no stiffeners.
Simple, economical.
Concentrically loaded columns; light to
moderate loads. IS code calls this a
'pinned base'.
Gusset Base
Base plate + two gusset plates +
gusset angles. Greater bearing area
and rigidity.
Heavily loaded columns; or where
bending moment is present. Can be
treated as a rigid base.
Welded Base
(Moment-
Resisting)
Thick plates with welded stiffeners,
connected to moment-resisting
frame. Covered in Appendix D of
McCormac.
Portal frames, moment frames,
cantilever columns — wherever full
fixity at base is required.
Grillage Footing
Two layers of steel I-beams
embedded in concrete. Very large
bearing areas.
Soft ground with very low soil bearing
capacity making large concrete blocks
uneconomical.
1.3 Slab Base — Structural Theory
The slab base design follows the cantilever plate bending model. The concrete pedestal applies a uniform upward
bearing pressure w (N/mm²) to the underside of the plate. The plate overhangs the column edge in two directions
— overhang a (greater) and overhang b (smaller).
1.3.1 Pressure Under the Plate
EACQ 3278 / EACR 3287 — Design of Structures B | Week 10: Foundations, Column Bases & Complete System Design
Bachelor of QS & Construction Management | Prepared from Duggal, McCormac & Salmon-Johnson | Page 3 of 23
w = P / A₁ [N/mm²]
where P = total axial load on column (N), and A₁ = area of base plate provided (mm²). The pressure is assumed to
be uniform for a concentrically loaded column (Duggal §5.3).
1.3.2 Bending Moments in the Plate
Taking a 1 mm wide strip cantilevered from the column edge, the maximum bending moment per unit width for
overhang a is:
Mₐ = w·a² / 2 [N·mm/mm]
And for overhang b:
M_b = w·b² / 2 [N·mm/mm]
The plate bends simultaneously about both principal axes. The stress from bending about one axis restrains the
bending about the other axis due to Poisson's ratio effects (μ = 0.25 for steel). The net bending stress relationship
(Duggal Eq. 5.6) is:
DERIVED THICKNESS FORMULA (Duggal Eq. 5.6):
t = √( 3w(a² − μb²) / σ_bs ) for a ≥ b
Where: t = minimum thickness of slab base (mm)
w = intensity of bearing pressure (N/mm²)
a = greater overhang of base plate (mm)
b = smaller overhang of base plate (mm)
μ = Poisson's ratio = 0.25 for steel
σ_bs = permissible bending stress in base = 185 MPa (IS code)
📝
When a ≈ b (near-square overhang), the thickness formula simplifies approximately to: t ≈
√(3w·a²·(1−μ)/σ_bs). In practice, designers often make the overhangs equal for simplicity.
1.4 Slab Base — Design Procedure (IS Code / Duggal §5.3)
The following step-by-step procedure is directly from Duggal Chapter 5:
1. Assume a suitable allowable bearing pressure on the concrete pedestal based on its grade. For M-15
concrete (fck = 15 N/mm²), the allowable bearing pressure = 0.25 fck = 3.75 N/mm².
2. Compute the required area of the base plate:
A_required = P / (allowable bearing pressure) [mm²]
3. Select the plate dimensions. For a square plate:
L = B = √A_required [mm] (round up to nearest 5 mm or 10 mm)
/ 23
